Up to 15 meter deep water installation possible
Smooth passage of solid materials up to half size of the pipe
Dry installation for easy maintenance
Supporting flexible installation according to on-site situation
1. Overview
Designed for dry installation scenarios where sewage is located underground at specific depths, the YW pump connects to the motor via a precision-coupled shaft, ensuring smooth operation with a submerged depth capability of up to 15 meters. Its vertical structure allows the pump body to remain immersed in liquid during operation, enabling easy startup without air exhaust or cavitation risks, while maintaining leak-free performance. The pump adopts a single or dual-channel impeller design paired with an optimized volute, achieving high efficiency and energy savings. The impeller undergoes dynamic/static balance testing to eliminate vibration during operation, offering features such as anti-clogging, anti-wrapping, and zero maintenance downtime. The pump capacity ranges from 4 to 3,000 m3/h with a maximum power of 250 KW.
2. Applications
● Urban Sewage Treatment: Used for lifting and transporting sewage in urban sewage treatment plants.
● Industrial Wastewater Treatment: Suitable for wastewater treatment in industries such as chemicals, pharmaceuticals, and papermaking.
● Agricultural Irrigation: Used in water pumping stations for agricultural irrigation systems.
● Other Applications: Such as drainage for civil defence systems, hospital sewage discharge, etc.
3. Characteristics
● Clog-free Design: It adopts large-passage anti-clogging hydraulic components, which can smoothly pass fiber materials more than 5 times the pump's diameter and solid particles with a diameter of about 50% of the pump's diameter, effectively avoiding clogging issues.
● High Efficiency and Energy Saving: The optimization of the pump body structure, coupled with a high-efficiency motor, results in lower energy consumption during pump operation, achieving remarkable energy-saving effects.
● Wear-resistant and Corrosion-resistant: The pump body and key components are made of wear-resistant and corrosion-resistant alloy materials, ensuring stable operation of the pump under harsh working conditions.
● Vertical Installation: The pump body is designed in a vertical structure, and it is fully submerged in the liquid during operation, allowing for easy starting without the need for venting, while also reducing the risk of leakage.
● Automatic Control: Equipped with a liquid level automatic control device according to user needs, enabling automatic start-stop of the pump and reducing manual operation costs.
● Easy Maintenance: The pump body is reasonably designed, making it easy to disassemble and clean, thus reducing the difficulty and cost of maintenance.
